Device labelling

The specifications in this user manual apply exclusively to the myDatalogEASY IoT ATEX device type. The type plates are located on the right side of the device and contains the following specifications:

  • Pin assignment of the connector for supply or charging voltage
  • Voltage supply specifications
  • Pin assignment of the connections for measurement channel 1 (red) and measurement channel 2 (yellow)
  • Type of the zener barrier installed in the measurement channel 1 (red)
  • Ex parameters of the zener barrier installed in the measurement channel 1 (red)
  • Type of the zener barrier installed in the measurement channel 2 (yellow)
  • Ex parameters of the zener barrier installed in the measurement channel 2 (yellow)
  • List of suitable power supply units
  • Hazard note regarding electrostatic charge build-up
  • Type designation
  • Serial number
  • Item number
  • Country list profile of the SIM chip
  • Hardware revision
  • Environmental conditions during operation
  • Protection class
  • Week and year of production
  • Ex protection designation as specified in chapter Declaration of conformity
  • CE marking
  • Logo for the EU WEEE Directive
  • Chargeable features that were unlocked at the time of delivery
  • Name and address of the manufacturer

The correct specification of the type designation and serial number is important for all queries and spare part orders. Only then can we process requests promptly and properly.

Type plates myDatalogEASY IoT ATEX

Tip: This symbol indicates the country list profile of the SIM chip installed in the device.

Note: These operating instructions are part of the device and must be available to the user at all times. The safety instructions contained therein must be observed.

Attention: It is strictly prohibited to disable the safety equipment or modify its mode of operation.
