Device labelling
The specifications in this user manual apply exclusively to the measurement system composed of the following components:
- BLE Gauge
- Pressure sensor
The type plates of the BLE Gauge are located on the top and sides of the device and contain the following specifications:
- Product designation
- Serial number
- Hardware revision
- Item number
- Ex protection designation as specified in chapter Declaration of conformity
- Week and year of production
- Name and address of the manufacturer
- Environmental conditions during operation
- Protection class
- Chemical composition of the battery installed
- Logo for the EU WEEE Directive
- CE marking
Type plates BLE Gauge
the type plate for the pressure sensor is located at the top end of the cable and contains the following specifications:
- Item number
- Measurement range (e.g. 0-10 m)
- Type of pressure sensor (e.g. "9" for PR-26D Ei series)
- Permitted substances (e.g. "W" for fresh and grey water)
Type plate pressure sensor
The correct specification of the product designation and serial number is important for all queries and spare part orders. Only then can we process requests promptly and properly.
